Deep hole drills
The right drill for every task
The process is referred to as deep hole drilling when the diameter-length ratio is 15xD or greater. Deep hole drills are used in the machining of drive shafts, injectors, drill rods in oil production, in the medical sector, in mould making and in the food industry. Depending on the machine specifications, the hole requirements, the lot size and the hole depth, Gühring determines the most effective tool option.
Single-fluted deep hole drills
Shining in the supreme discipline
Deep hole drilling is one of the most challenging tasks in machining. However, there are several factors you need to consider to reduce the risk of tool breakage. You can find out how to use single-fluted deep hole drills correctly in the video.
You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More Information
Single-fluted deep hole drill
EB 100 M
Monolithic design for enhanced performance
With the EB 100 M, Gühring offers a very robust solid carbide single-fluted deep hole for particularly tight drilling tolerances. As the tool does not require a solder joint, it guarantees higher stability and therefore 20-30% higher feed rates.
Your benefits with the EB 100 M:
- nom. Ø from 1,000 mm to 16,000 mm
- flute length up to 580 mm
- drilling up to 80xD with a single tool
- suitable for almost all materials
Single-fluted deep hole drill
EB 100
Our smallest solid carbide single-fluted deep hole drill
Maximum stability even at minimal diameters that’s the promise of the solid carbide single-fluted deep hole drill EB 100. The tool can be produced from a nominal diameter of 0.9 mm and is therefore also suitable for deep-hole drilling in the micro range.
Your benefits with the EB 100:
- nom. Ø from 0.900 mm to 16.000 mm
- flute length up to 580 mm
- up to 80xD with a single tool
- suitable for almost all materials
Single-fluted deep hole drill
EB 80
Classic single-fluted deep hole drill with carbide head
The EB 80 is our classic single-fluted deep hole drill with steel shank and brazed carbide head. The tool can be used flexibly and is available, for example, as a version for step drilling.
Your benefits with the EB 80:
- total length up to 3,600 mm
- XXL version with total length to 2000 mm available from warehouse
- nom. Ø from 2,000 mm to 40,000 mm
- large variety of designs, e.g. with full radius or as step drill
Single-fluted deep hole drill
EB 800
Flexible deep hole drill with system
The single-fluted deep hole drill with interchangeable inserts and interchangeable supporting strips is suitable for machining almost all materials. Thanks to the precision interchangeable inserts and supporting strips, no complicated adjustment is necessary.
Your benefits with the EB 800:
- total length of up to 3,600 mm
- nom. Ø from 12,000 mm to 52,000 mm
- any coating possible
- suitable for almost all materials
Two-fluted deep hole drills
Drilling with depth accuracy
Gühring’s two-fluted deep hole drills ensure precise, deep holes with a consistent diameter. In addition, two-fluted deep hole drills generally allow for higher feed rates than single-fluted deep hole drills.
Two-fluted deep hole drill
ZB 80
The specialist for cast iron
The ZB 80 two-fluted deep hole drill has a brazed carbide head whose substrate and cutting edge geometry have been specially developed for machining of cast materials.
Your advantages with the ZB 80:
- total length up to 1,000 mm
- nom. Ø from 6,000 mm to 30,000 mm
- perfect for the machining of castings
Spiral deep hole drills
Spiralised chips
The highest feed rates and cutting speeds are only possible if a safe chip removal is ensured. The spiral deep hole drill RT 100 T achieves this. The video shows the solid carbide drill in action when machining a crankshaft.
You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationProblem-free chips
The spiral deep hole drills feature a special flute geometry that ensures optimum chip removal from the hole. In order to optimally supply the cutting edge with coolant, the tools have coolant ducts with a maximum cross-section. This ensures an effective supply of coolant to the cutting edge as well as an excellent chip removal. These factors — in combination with cutting parameters perfectly matched to the application — result in chips that are easily removed even from deep holes. This effectively prevents chip jam and the associated jamming of the tool.
Spiralised solid carbide-deep hole drill
RT 100 T
Process-reliable drilling of up to 40xD
With the RT 100 T, the user benefits from the highest feed rates and cutting speeds, and therefore from a significant reduction in production times.
Your benefits with the RT 100 T:
- optimised flute cross-section for reliable chip transport from deep holes
- effective coolant supply thanks to maximum coolant duct cross-section
- tip coating with the Gühring A-coating (TiAlN)
HSS-E-PM deep hole drill
GT 2000
Drilling depths of up to 20xD without chip-breaking cycles
The spiral deep hole drill GT 2000 is particularly suitable for steel machining. The TiAlN-based tip coating ensures high wear resistance of the cutting edge, which is heavily loaded in the machining.
Your advantages with the GT 2000:
- up to 20xD drilling depth
- drill point with optimised S-web thinning
- parabolic flute shape with optimised surface quality ensures best chip formation
- blank flute with high surface quality for perfect chip removal
AcademyFour-fluted drills
Revolution of cast machining
Where deep holes need to be drilled in parts of the powertrain, these tools are the specialists. However, not only a large diameter range can be produced with the four-fluted drill, but also drilling depths of up to 40xD. And all this at an unbeatable speed.
You are currently viewing a placeholder content from YouTube. To access the actual content, click the button below. Please note that doing so will share data with third-party providers.
More InformationTwo tools, one power technology: with the four-fluted deep hole drill VB80 and the four-fluted drill VB100, which are used for drilling, pilot holes and step drilling, Gühring is revolutionising the machining of castings. Compared to conventional drilling processes, at least twice the speed is possible here. For the machinist, this means significant cycle time savings of several minutes and massive increases in capacity.
Deep hole drill
VB80
Maximum chip volume up to 40xD
The VB80 was specially designed for high metal removal rates in the machining of castings. The four-fluted drill has a solid body made of solid carbide with a length of 240 mm and straight flutes, onto which a solid carbide head is brazed with a positive fit.
Your advantages with the VB80:
- tool lives of up to 250 m in GG25
- diameter from 8 to 30 mm and tool lengths up to 1,000 mm
- patented 2+4-cutting edge distribution
Four-fluted drill
VB100 P
High feed drilling for reduced cycle times
The VB100 P impresses with the cost-effective machining of cast materials with extreme cutting performance. The drill is designed with a 2 and 4-fluted configuration to handle large chip volumes. This results in shorter chips, higher cutting parameters and greater process reliability.
Your advantages with the VB100 P:
- optimised removal of the chips
- increased position accuracy
- maximised tool life due to reduced intervention time
